STEC AXIS 10
The STEC AXIS10 is a fully motorized, high performance robotic total station designed for single operator (one-man) geodetic surveying, stakeout, and data collection.
Fast intelligent prism tracking that makes surveying more precise, efficient, and effortless.
180º/s
torque-drive
1000m
prism recognize
300m
prism search
20º/s
tracking speed
0.5/1"
angle accuracy
1+1ppm
distance accuarcy
600m
remote control
6"
touch screen
Robotic Precision. Effortless Tracking. Maximum Productivity.
High-Speed 180°/s Motor for Fast and Precise Positioning
The Torque Drive 2.0 features a maximum motor rotation speed of 180° per second, enabling fast, precise, and stable positioning. Its high-speed motor supports rapid prism searching and target acquisition while improving tracking performance during robotic surveying. This makes it ideal for repetitive and high-frequency survey measurements, helping reduce positioning time and increase overall field productivity.
AUTOMATIC PRISM LOCK & TRACKING
xTrak Prism Lock & Tracking automatically locates, locks onto, and continuously tracks the prism at up to 20°/s, maintaining alignment as the surveyor moves and helping recover the target after brief obstructions such as trees, vehicles, or other obstacles.
6 INCH COLOR TOUCH SCREEN
providing a larger interface for:
- Field surveying
- CAD drawings
- Stakeout
- Point management
- Measurement
- Instrument control
FLEXIBLE CONNECTIVITY
AXIS10 offers superior connectivity with USB,Wi-Fi, Bluetooth, long-range Bluetooth, serial port, and a SIM card slot, enabling effortless data exchange and remote control.
GENIUS FOR MONITORING
AXIS10 can be adapted to your own monitoring software after debugging. We also offer a specialized option designed for real-time data collection, processing, and management in monitoring applications.
MAIN BENEFITS
Dual-axis compensation helps correct small instrument tilts within its operating range.
IP65 protection on the listed specification helps protect against dust and water jets.
Compatible remote-control options can help the surveyor work independently from the instrument
Up to 3,500 m with a single prism according to the detailed
The manufacturer specifies up to 16 hours of battery operation. Its IP55 rating provides protection against dust ingress and water jets, but it should not be treated as waterproof or suitable for submersion.
